Manufacturers and Distributors of Quality Scales and Weighbridges
INDICATORS
QW-INTELLIWEIGH LCD + RS-232
FEATURES
-
Animal weighing
-
Counting function
-
Connect with mini-printer
-
LO-OK-HI Set point
-
Plastic housing and stainless steel holder
-
6 Digit 25.4mm LCD
-
Dimensions: 265mm X 150mm X 136mm
-
Weight: 1.5kg
-
Inside battery: 6V 2.8AH
SHOP NOW
-
20 Hours of full charge battery operation
-
Drive up 4X350 Ohm or 8X700 Ohm load cell
-
Manual/Automatic accumulation
-
Programable zero tracking
-
Programmable digital filter
-
Selectable kg and lb
-
RS-232 Serial Interface
-
Accuracy can be increased 10 times
-
Hold function
QW-INTELLIWEIGH STAINLESS STEEL LCD + RS-232
FEATURES
-
Animal weighing
-
Counting function
-
Connect with mini-printer
-
LO-OK-HI Set point
-
Waterproof, dustproof stainless steel housing
-
6 Digit 25.4mm LED
-
Dimensions: 265mm X 150mm X 136mm
-
Weight: 1.5kg
-
Inside battery: 6V 2.8AH
-
20 Hours of full charge battery operation
-
Drive up 4X350 Ohm or 8X700 Ohm load cell
-
Manual/Automatic accumulation
-
Programable zero tracking
-
Programmable digital filter
-
Selectable kg and lb
-
RS-232 Serial Interface
-
Accuracy can be increased 10 times
-
Hold function
SHOP NOW
QW-INTELLIWEIGH LED + RS-232
FEATURES
-
Animal weighing
-
Counting function
-
Connect with mini-printer
-
LO-OK-HI Set point
-
Plastic housing and stainless steel holder
-
6 Digit 20.2mm LED
-
Dimensions: 265mm X 150mm X 136mm
-
Weight: 1.5kg
-
Inside battery: 6V 2.8AH
-
20 Hours of full charge battery operation
-
Drive up 4X350 Ohm or 8X700 Ohm load cell
-
Manual/Automatic accumulation
-
Programable zero tracking
-
Programmable digital filter
-
Selectable kg and lb
-
RS-232 Serial Interface
-
Accuracy can be increased 10 times
-
Hold function
SHOP NOW
QW-T16 INDICATOR
FEATURES
-
Drive up 4X350 ohm load cell
-
Programmable zero tracking
-
Programmable digital filter
-
Selectable kg and lb
-
Counting function
-
Animal Weighing
-
Accumulation
-
Includes rechargeable battery and mains supplied as standard with 40 hours standby
-
Industrial finish to protect against elements
-
Stainless steel housing
-
Supplied with pillar bracket and connector
SHOP NOW
QW-T23 INDICATOR
FEATURES
-
Drive up 4X350 Ohm load cell
-
Programmable zero tracking
-
Programmable digital filter
-
Selectable kg and lb
-
Counting function
-
Animal Weighing
-
Accumulation function
-
Includes rechargeable battery and mains supplied as standard with 40 hours standby
-
Industrial finish to protect against elements
-
Stainless steel housing
-
Supplied with connector
SHOP NOW
SHOP NOW
-
Plastic Housing
-
0.4 inch red LED Display
-
Dimensions: 95mm (W) X 48mm (H) X 110mm (D)
-
Weight: 0.5kg
-
∑Δ type A/D converter, with an A/D resolution better than 1,000,000. A/D conversion speed of 10 times per second.
-
5V DC bridge supply voltage, capable of connecting four 350-
ohm sensors or eight 700-ohm sensors
-
4-20mA analog current output
-
6 relay outputs, 2 isolated digital inputs
-
Isolated RS485 bidirectional communication / isolated RS232C continuous unidirectional output
-
DC9V power supply (Model A optional AC110-220V power supply)
QW-XK315A2-6
FEATURES
